Acoustic Guitars

• Serial Number:  OF422002007004
• Weight: 4.8lbs

SPECS

Designed for Travel

• The Overhead travel guitar uses a patented collapsible neck system which allows for assembly/disassembly in a matter of seconds.
• After packing in its travel backpack the Overhead travel guitar can be carried-on to most major airlines, easily fitting in the overhead bin compartment.
• Travel backpack includes a TSA compliant laptop tablet fold-out panel which can be scanned by airport security without having to separately remove laptop.
• Proprietary under-bridge transducer pickup system accurately amplifies the guitar and comes with all Overhead guitars.

Full Tone in a Travel Body

• The wedge design gives a lower shoulder/bout depth that’s deeper than a dreadnought, allowing the smaller body size to deliver great volume and booming bass.
• Bone nut, compensated bone saddle, and ebony bridge pins all help produce the the tone preferred by acoustic guitarists.
• Traditional sound-hole design with forward-shifted, tapered  X-bracing maximizes the resonance and volume of the soundboard.

Comfortable to Play

• The wedge design angles the guitar into your body which places the guitar in a comfortable position for fingerboard access and viewing.
• The dual-action steel truss-rod enables fine tuning of relief to suit any playing style.
• Satin-finish low-c profile neck make this 24.5 inch scale super comfortable to play.

Guitar Specifications

Proprietary Body Design:

• Stylized 00 body shape
• Center sound hole with Pau Ferro rosette
• Wedge design for increased volume, comfort and efficiency

Soundboard:

• Hand-selected Premium Solid Sitka Spruce

Back and Sides:

• Premium Solid Pau Ferro back, laminate sides

Bracing:

• Forward-shifted tapered  X-bracing
• Compound block for reduced weight and strengthened latch support

Binding and Markings:

• MOP logo and position markings
• Maple binding

Scale:

• 24.5 in (622.3 mm)

Finish:

• Satin on soundboard, back, and sides

Bridge:

• Ovangkol, high break-angle

Tuners:

• Grover® 18:1 or Journey 18:1 Locking Tuners

Electronics:

Removable Neck Assembly:

• Stainless steel load-bearing components
• Push-button release latch under neck
• Large adjustment knob on back

Neck:

• Carbon fiber reinforced traditional C shape with two-way adjustable truss rod
• Solid African Mahogany
• Deep-slotted bone nut
• Neck width at nut: 1 ¾ in (44.5 mm)
• Neck width at 12th fret: 2.2 in (56 mm)
• 14 Frets to body
• 20 Frets total

Fret Board:

• 16 inch Radius, Ovangkol
• Medium brass fret wire

String Spacing:

• 2 ¼ in (>57.2mm)
• Compensated bone saddle

Strings:

• Elixir® Phosphor-Bronze Lights

Guitar Dimensions and Weights:

• Weight: 4.4 lbs (2.0kg)
• Weight With Case: 7.4 lbs (3.3kg)

• Maximum depth: 4.64 in (11.8cm)
• Minimum Depth: 3.5 in (8.9 cm)
• Body Length: 18 in (45.7cm)
• Total Length: 35.5 in (90cm)
• Lower Bout Width: 13.25 in (33.7 cm)

Travel Backpack Specifications

Tech Travel Ready:
TSA compliant 14-inch computer compartment for optimal airport security inspection
Easy-access tablet pocket for up to 9.5 inch tablet devices

All- Premium Material Construction:
Extra-durable Ballistic Polyester external case with premium polyester and velour lining
Extra-padded Body compartment with premium velour
Internally-accessible padded neck compartment with premium velour and string slot
Padded string panel with strings positioning tab
Padded Top and Side handles

Extra Compartments for Your Journey:
Internal/externally accessible compartment for accessories
Additional external topside pocket for additional accessories
Additional elastic pockets in computer compartment
Hideaway, reinforced padded backpack straps with padded back

Maximum Case Dimensions: L*W*H: 22*14*9 in ( 55.9*35.5* 22.9 cm)

Note: Some cases may open from the opposite side to accomodate additional guitar models that share the same guitar case.

UPC:643485844280

• Serial Number:  OF660002202008
• Weight: 5.0lbs

SPECS

• Serial Number:  OF660B1M2204003
• Weight: 4.8lbs

SPECS

Designed for Travel

• The Overhead™ travel guitar uses a patented collapsible neck system which allows for assembly/disassembly in a matter of seconds.
• After packing in its travel backpack the Overhead travel guitar can be carried-on to most major airlines, easily fitting in the overhead bin compartment.
• Travel backpack includes a TSA compliant laptop tablet fold-out panel which can be scanned by airport security without having to separately remove laptop.
• Proprietary under-bridge transducer pickup system accurately amplifies the guitar and comes with all Overhead guitars.

Full Tone in a Travel Body

• The wedge design gives a lower shoulder/bout depth that’s deeper than a dreadnought, allowing the smaller body size to deliver great volume and booming bass.
• Bone nut, compensated bone saddle, and ebony bridge pins all help produce the tone preferred by acoustic guitarists.
• Offset sound-hole design maximizes the resonance and volume of the soundboard and proprietary bracing and layup structure produce a spectacular tone for such a compact instrument.

Comfortable to Play

• The wedge design angles the guitar into your body which places the guitar in a comfortable position for fingerboard access and viewing.
• The dual-action steel truss-rod enables fine tuning of relief to suit any playing style.
• Satin-finish low-c profile neck make this 24.5 inch scale super comfortable to play.
• Scoop-away™ design gives full access to all 20 frets, yet maximizes inner air volume of the instrument for maximum acoustical volume.

Guitar Specifications

Proprietary Body Design:

• Stylized 00 body shape
• Mid-position offset sound hole for maximum resonance
• Scoopaway™ for access to all 20 frets while maintaining maximum volume
• Beveled back for maximum playing comfort
• Wedge design for increased volume, comfort and efficiency
• Beveled soundboard armrest for maximum comfort

Soundboard:

• Unidirectional carbon fiber with proprietary carbon fiber bracing

Back and Sides:

• Fiberglass reinforced carbon fiber

Markings:

• MOP logo and position markings

Scale:

• 24.5 in (622.3 mm)

Finish:

• High gloss polyurethane

Bridge:

• Carbon Fiber, high break-angle

Tuners:

• Grover® 18:1 or Journey 18:1 Locking Tuners

Electronics:

• Stainless steel load-bearing components
• Push-button release latch under neck
• Large adjustment knob on back

Neck:

• Carbon fiber reinforced traditional C shape with two-way adjustable truss rod
• Deep-slotted bone nut
• Neck width at nut: 1 ¾ in (44.5 mm)
• Neck width at 12th fret: 2.2 in (56 mm)
• Neck  Thickness at 1st fret: 0.86 in(21.8mm)
• Neck  Thickness at 5th fret:0.91 in(23mm)
• Neck  Thickness at 9th fret:0.96 in(24.5mm)
• 14 Frets to body
• 20 Frets total

Fret Board:

• 16 inch Radius, Carbon Fiber
• Jumbo hardened nickel-brass alloy fret wire

String Spacing:

• 38 mm at nut
• 56.6 mm at saddle

• Compensated bone saddle

Strings:

• D’Addario EXP16 Coated Phosphor Bronze Acoustic Guitar Strings, Light, 12-53

Guitar Dimensions and Weights:

• Weight: 5 lbs (2.2kg)
• Weight With Case: 7.9 lbs (3.6kg)

• Maximum depth: 4.64 in (11.8cm)
• Minimum Depth: 3.5 in (8.9 cm)
• Body Length: 18 in (45.7cm)
• Total Length: 35.5 in (92cm)
• Lower Bout Width: 12.5 in (31.8 cm)
• Maximum Case Dimensions: L*W*H: 22*14*10 in (55.9*35.5* 22.9 cm)

Travel Backpack Specifications

Tech Travel Ready:
TSA compliant 14-inch computer compartment for optimal airport security inspection
Easy-access tablet pocket for up to 9.5 inch tablet devices

All- Premium Material Construction:
Extra-durable Ballistic Polyester external case with premium polyester and velour lining
Extra-padded Body compartment with premium velour
Internally-accessible padded neck compartment with premium velour and string slot
Padded string panel with strings positioning tab
Padded Top and Side handles

Extra Compartments for Your Journey:
Internal/externally accessible compartment for accessories
Additional external topside pocket for additional accessories
Additional elastic pockets in computer compartment
Hideaway, reinforced padded backpack straps with padded back

Maximum Case Dimensions: L*W*H: 22*14*9 in ( 55.9*35.5* 22.9 cm)

Note: Some cases may open from the opposite side to accomodate additional guitar models that share the same guitar case.

UPC:643485843948

• Serial Number:  OF660M02207012
• Weight: 5.0lbs

SPECS

Designed for Travel

• The Overhead™ travel guitar uses a patented collapsible neck system which allows for assembly/disassembly in a matter of seconds.
• After packing in its travel backpack the Overhead travel guitar can be carried-on to most major airlines, easily fitting in the overhead bin compartment.
• Travel backpack includes a TSA compliant laptop tablet fold-out panel which can be scanned by airport security without having to separately remove laptop.
• Proprietary under-bridge transducer pickup system accurately amplifies the guitar and comes with all Overhead guitars.

Full Tone in a Travel Body

• The wedge design gives a lower shoulder/bout depth that’s deeper than a dreadnought, allowing the smaller body size to deliver great volume and booming bass.
• Bone nut, compensated bone saddle, and ebony bridge pins all help produce the tone preferred by acoustic guitarists.
• Offset sound-hole design maximizes the resonance and volume of the soundboard and proprietary bracing and layup structure produce a spectacular tone for such a compact instrument.

Comfortable to Play

• The wedge design angles the guitar into your body which places the guitar in a comfortable position for fingerboard access and viewing.
• The dual-action steel truss-rod enables fine tuning of relief to suit any playing style.
• Matte-finish low-c profile neck make this 24.5 inch scale super comfortable to play.
• Scoop-away™ design gives full access to all 20 frets, yet maximizes inner air volume of the instrument for maximum acoustical volume.

Guitar Specifications

Proprietary Body Design:

• Stylized 00 body shape
• Mid-position offset sound hole for maximum resonance
• Scoopaway™ for access to all 20 frets while maintaining maximum volume
• Beveled back for maximum playing comfort
• Wedge design for increased volume, comfort and efficiency
• Beveled soundboard armrest for maximum comfort

Soundboard:

• Unidirectional carbon fiber with proprietary carbon fiber bracing

Back and Sides:

• Fiberglass reinforced carbon fiber

Markings:

• MOP logo and position markings

Scale:

• 24.5 in (622.3 mm)

Finish:

• Matte polyurethane

Bridge:

• Carbon Fiber, high break-angle

Tuners:

• Grover®  18:1 or Journey 18:1 Locking Tuners

Electronics:

Removable Neck Assembly:

• Stainless steel load-bearing components
• Push-button release latch under neck
• Large adjustment knob on back

Neck:

• Carbon fiber reinforced traditional C shape with two-way adjustable truss rod
• Deep-slotted bone nut
• Neck width at nut: 1 ¾ in (44.5 mm)
• Neck width at 12th fret: 2.2 in (56 mm)
• Neck  Thickness at 1st fret: 0.86 in(21.8mm)
• Neck  Thickness at 5th fret:0.91 in(23mm)
• Neck  Thickness at 9th fret:0.96 in(24.5mm)
• 14 Frets to body
• 20 Frets total

Fret Board:

• 16 inch Radius, Carbon Fiber
• Jumbo hardened nickel-brass alloy fret wire

String Spacing:

• 2 ¼ in (>57.2mm)
• Compensated bone saddle

Strings:

• D’Addario EXP16 Coated Phosphor Bronze Acoustic Guitar Strings, Light, 12-53

Guitar Dimensions and Weights:

• Weight: 4.6 lbs (2.1kg)
• Weight With Case: 7.9 lbs (3.6kg)

• Maximum depth: 4.64 in (11.8cm)
• Minimum Depth: 3.5 in (8.9 cm)
• Body Length: 18 in (45.7cm)
• Total Length: 35.5 in (92cm)
• Lower Bout Width: 12.5 in (31.8 cm)
• Maximum Case Dimensions: L*W*H: 22*14*9 in (55.9*35.5* 22.9 cm)

Travel Backpack Specifications

Tech Travel Ready:
TSA compliant 14-inch computer compartment for optimal airport security inspection
Easy-access tablet pocket for up to 9.5 inch tablet devices

All- Premium Material Construction:
Extra-durable Ballistic Polyester external case with premium polyester and velour lining
Extra-padded Body compartment with premium velour
Internally-accessible padded neck compartment with premium velour and string slot
Padded string panel with strings positioning tab
Padded Top and Side handles

Extra Compartments for Your Journey:
Internal/externally accessible compartment for accessories
Additional external topside pocket for additional accessories
Additional elastic pockets in computer compartment
Hideaway, reinforced padded backpack straps with padded back

Maximum Case Dimensions: L*W*H: 22*14*9 in ( 55.9*35.5* 22.9 cm)

Note: Some cases may open from the opposite side to accomodate additional guitar models that share the same guitar case.

UPC:643485843405
