Audio & Processing
-
Sample Rate: 48 kHz
-
AD Conversion: 24-bit + AF method
-
AF (Adaptive Focus) Method: Proprietary technology from Roland and BOSS that improves the signal-to-noise (S/N) ratio of the AD and DA converters
-
-
DA Conversion: 32-bit
-
Internal Processing: 32-bit floating point
Effects & Memory
-
Effects Types: 39
-
Memories:
-
99 User
-
50 Preset
-
-
Phrase Loop Time: 37 seconds
Input Specifications
Nominal Input Level
-
INPUT: -40 dBu (adjustable)
-
AUX IN: -20 dBu
Maximum Input Level
-
INPUT: 0 dBu
-
AUX IN: 0 dBu
Input Impedance
-
INPUT: 4 kΩ
-
AUX IN: 27 kΩ
Output Specifications
Nominal Output Level
-
OUTPUT L/MONO, R: -40 dBu
-
PHONES/LINE OUT: -10 dBu
Output Impedance
-
OUTPUT L/MONO, R: 600 Ω
-
PHONES/LINE OUT: 47 Ω
Recommended Load Impedance
-
OUTPUT L/MONO, R: 600 Ω or greater
-
PHONES/LINE OUT: 47 Ω or greater
Display
-
Graphic color LCD
-
320 × 240 dots
Controls
-
HARMONY switch
-
DOWN switch
-
UP switch
-
MENU button
-
EXIT button
-
PHONES/LINE knob
-
MEMORY knob
-
HARMONY knob
-
EFFECT knob
-
ECHO knob
-
MIC SENS knob
-
PHANTOM switch
-
POWER switch
Connectors
-
INPUT: XLR type, balanced, phantom power (DC 48 V, 10 mA max)
-
OUTPUT L/MONO, R: XLR type
-
PHONES/LINE OUT: Stereo miniature phone type
-
AUX IN: Stereo miniature phone type
-
CTL1,2 / EXP: 1/4-inch TRS phone type
-
USB COMPUTER port: USB Type-C
-
DC IN jack
Power
Power Supply
-
4 × AA (LR6) alkaline batteries
or -
AC adaptor (PSA-S series, sold separately)
Current Draw
-
260 mA (with phantom power)
-
180 mA (without phantom power)
Expected Battery Life (Continuous Use)
-
Approx. 6 hours (with phantom power)
-
Approx. 9 hours (without phantom power)
Battery life may vary depending on battery specifications, capacity, and usage conditions.
Accessories (Included)
-
Startup Guide
-
4 × AA (LR6) alkaline batteries
-
“Using the Unit Safely” leaflet
Options (Sold Separately)
-
AC adaptor: PSA-S series
-
Footswitch: FS-5U, FS-6, FS-7
-
Expression Pedals: EV-30, FV-500L, FV-500H, Roland EV-5
-
Carrying Bag: CB-VE22
Size & Weight
-
Width: 218 mm (8-5/8 in.)
-
Depth: 143 mm (5-11/16 in.)
-
Height: 64 mm (2-9/16 in.)
-
Weight (including batteries): 910 g (2 lb 0.1 oz)
